Computer Control Servo Hydraulic Universal Testing Machine (SCH Series)

Send Inquiry

Request To Call Back

Computer Control Servo Hydraulic Universal Testing Machine (SCH Series)

Get a Price/Quote

MOQ : 1 Number

Computer Control Servo Hydraulic Universal Testing Machine (SCH Series) Specification

Response Time
≤10 ms

Application
Tensile, Compression, Bending, Shear Testing of Metals and Non-metals

Automation Grade
Automatic

Voltage
AC 380 Volt (v)

Max Height
approx. 2100 mm

Power Supply
3-Phase

Features
Overload Protection, Automatic Data Processing, Multilingual Software, Curve Display

Test Range
2%—100% FS

Frequency
50Hz

Accuracy
Class 1 or Class 0.5

Mounting Type
Floor Mounted

Resolution
1/500000

Humidity
≤85% (relative)

Hardness
Industrial Grade Components

Temperature
10°C—35°C

Display Type
LCD / Computer Screen

Operating Voltage
AC 380V ±10%, 50Hz

Port Size
Customizable

Specimen Size
Round: ø10–ø40 mm, Flat: up to 70×20 mm

Gas Pressure
0.6 MPa

Measuring Range
0.2%—100%FS

Number of Specimens
Single or Multiple

Interface Type
USB / RS232

Equipment Type
Universal Testing Machine

Usage
Laboratory, Research, Quality Control

Capacity
100kN / 200kN / 300kN / 600kN / 1000kN

Machine Weight
1800 to 1950 Kilograms (kg)

Test Speed
0.01—300 mm/min

Test Width
510 mm

Test Stroke
500 mm

Control Mode
Computer Controlled / Servo Hydraulic

Computer Control Servo Hydraulic Universal Testing Machine (SCH Series) Trade Information

Minimum Order Quantity
1 Number

Supply Ability
1 Number Per Week

Delivery Time
1 Week

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Computer Control Servo Hydraulic Universal Testing Machine (SCH Series)

Features

Fully computer control testing process.

Front open hydraulic automatic clamping.

Stable and reliable high intensity 4 columns and 2 reeling screw column structure load frame.

Auto detection of over load, over travel & specimen break. On detection of any of these conditions, the hydraulic motor is automatically switched off.

Wide range of testing speed allow testing of various metals as per ASTM, ISO and IS standard.

All machine of frame size is different as per capacity.

Precision Engineering for Diverse Testing Needs

The SCH Series offers exceptional accuracy, featuring Class 1 or Class 0.5 measurement standards and a wide test range (2%-100%FS). Its centralized automatic lubrication and response time 10 ms ensure consistent, reliable results, making it suitable for tensile, compression, bending, and shear testing of various materials.

Intelligent Control and Seamless Data Handling

Equipped with computer-controlled, servo hydraulic technology, the SCH Series uses Windows-based software for intuitive analysis and control. Multilingual support, automatic data processing, and curve display enhance workflow. Export results effortlessly to Excel, PDF, or database for comprehensive reporting and traceability.

Comprehensive Safety and Compliance

Ensuring operator safety, the SCH Series includes emergency stop buttons, software interlocks, and limit switch protection. Fully compliant with ISO, ASTM, and GB standards, the machine supports laboratory, research, and quality control functions with industrial-grade components and reliable overload protection.

FAQs of Computer Control Servo Hydraulic Universal Testing Machine (SCH Series):

Q: How does the SCH Series Universal Testing Machine maintain precise measurement accuracy?

A: The SCH Series uses a high precision load cell and advanced servo hydraulic controls, adhering to Class 1 or Class 0.5 standards. Its resolution (1/500000) and rapid response time (10 ms) ensure accurate force, displacement, and deformation readings.

Q: What types of materials and tests can be performed with this equipment?

A: This machine is designed for tensile, compression, bending, and shear testing of both metals and non-metals. It accommodates round specimens (1040 mm) and flat specimens (up to 7020 mm), with capacities ranging from 100kN to 1000kN.

Q: When should I use hydraulic, manual, or automatic clamping for my tests?

A: Hydraulic clamping is ideal for frequent, high-force tests and ensures uniform gripping. Manual clamping suits less intensive or smaller-scale applications, while automatic clamping maximizes efficiency in repetitive testing or automation processes.

Q: Where can test results be exported and in which formats?

A: Test results can be exported directly from the control software to Excel sheets, PDF documents, or database formats, supporting easy integration into laboratory management or quality assurance systems.

Q: What safety features are included to protect users and specimens?

A: The SCH Series incorporates emergency stop buttons, software interlock mechanisms, and limit switch protection to prevent accidents, equipment overloads, or unintended machine operations during testing procedures.

Q: How is the machine beneficial for laboratory and industrial use?

A: Its automated operation, high measurement accuracy, versatile testing modes (constant force/displacement/deformation), and robust frame make it essential for quality control, research, and certification of materials, improving productivity and reliability.

Q: What is the process for controlling and analyzing tests on this machine?

A: Tests are set up and executed via intuitive Windows-based control software. Users can select testing modes, monitor real-time data on an LCD or computer screen, utilize curve displays, and automate data processing for comprehensive analysis and reporting.
