Computerized Digital Micro Vickers Hardness Tester (HT-1000AD with VIDAS 2.0)

Name: Computerized Digital Micro Vickers Hardness Tester (HT-1000AD with VIDAS 2.0)
Brand: OM ENGINEERING INSTRUMENTS
Price: 1 INR
Availability: InStock

Price 1 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Computerized Digital Micro Vickers Hardness Tester (HT-1000AD with VIDAS 2.0) Specification

Number of Specimens
Supports single and batch specimen testing

Operating Voltage
AC220V±5%

Port Size
Standard testing port

Test Range
1HV – 3000HV

Hardness
Micro Vickers (HV) measurement

Application
Material and metallurgical hardness measurement

Frequency
50-60 Hz

Power Supply
AC220V±5% 50-60Hz

Specimen Size
Maximum 200 mm width

Interface Type
USB, RS-232C

Max Height
530 mm

Features
VIDAS 2.0 software, digital image analysis, statistical data processing, automatic turret, motorized focusing

Response Time
Instant digital reading (within 1 sec)

Measuring Range
1HV – 3000HV (Vickers hardness)

Dimension (L*W*H)
530X200X530 Millimeter (mm)

Temperature
10°C – 35°C operating range

Accuracy
±2% of measured value

Humidity
≤85% RH

Equipment Type
Computerized Digital Micro Vickers Hardness Tester

Resolution
0.1 HV

Automation Grade
Automatic

Display Type
Touchscreen Digital Display

Mounting Type
Bench-top mounting

Usage
Micro Vickers hardness testing for research, quality control

Capacity
Optimized for micro-Hardness testing

Machine Weight
35 Kilograms (kg)

Test Speed
Standard micro-indentation speed

Test Width
200 mm

Test Stroke
Up to 530 mm

Control Mode
Computerized Digital Control with VIDAS 2.0

Computerized Digital Micro Vickers Hardness Tester (HT-1000AD with VIDAS 2.0) Trade Information

Minimum Order Quantity
1 Number

Payment Terms
Cheque, Telegraphic Transfer (T/T)

Supply Ability
1 Number Per Day

Delivery Time
1 Week

Main Domestic Market
All India

About Computerized Digital Micro Vickers Hardness Tester (HT-1000AD with VIDAS 2.0)

Features

DIGITAL EYEPIECE :Equipped with 10x Digital Eyepiece to directly measure the length of the diagonal. The hardness value can be displayed directly and there is no need to enter the length of the diagonal.

CAMERA PORT :Machine equipped with dual optical channel. 5 Mega Pixel USB Camera is connected to one of the dual optical channels, other optical channel is for 10X eyepiece. Both optical channel works simultaneously.

ILLUMINATION SYSTEM :Halogen illumination unit with adjustable intensity gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.

TEST FORCE :Wide range of test force (10gm to 1000gm) can be selected with external force selection knob. The test force is automatically displayed on the 75X100mm LCD Screen.

DATA OUTPUT :Equipped with built-in thermal printer to take the print out the hardness result.

AUTO TURRET MECHANISM :Equipped with auto turret mechanism. Auto turret perform a series of operation and measuring lens automatically comes back to central position after making indentation. The position of the indenter and the objective lens can be automatically switched using touch panel.

Z-AXIS LIFTING SYSTEM :Side-Ways lifting system makes the z-axis movement more stable and accurate.

LCD SCREEN PANEL :75X100mm LCD screen can visually display the hardness value, conversion hardness, test force, dwell time, statistical data, upper & lower limit and brightness of optical system.

EMERGENCY SWITCH :Equipped with emergency stop switch.

Advanced Automation and Precision

HT-1000ADs automated loading system guarantees consistent hardness measurements across single and multiple specimens. Motorized focus and turret simplify sample setup, while the diamond Vickers indenter ensures reliable micro-indentation and repeatable results. With a broad force range and rapid response time, the system is ideal for laboratories demanding precision and efficiency.

Intuitive Interface and Data Management

Utilizing a high-resolution digital camera and a touchscreen display, the tester provides instant image capture and digital readouts. Internal and USB storage options enable robust data management, while VIDAS 2.0 software offers versatile statistical analysis tools. The user-friendly control mode streamlines both routine and complex testing processes, supporting easy export and review of results.

Versatile Sample Handling and Applications

The universal adjustable sample holder accommodates a variety of specimen sizes (up to 200 mm width), making the HT-1000AD suited for material testing, metallurgical research, and quality assurance workflows. Automated calibration and batch testing capability further extend its utility, ensuring reliability even with diverse sample sets.

FAQs of Computerized Digital Micro Vickers Hardness Tester (HT-1000AD with VIDAS 2.0):

Q: How does the automated loading system of the HT-1000AD improve testing accuracy?

A: The automated loading system applies selectable forces from 10g to 1000g with precision, minimizing human error and guaranteeing consistent indentation results for all specimens tested.

Q: What is the range of specimen sizes that can be tested with this hardness tester?

A: The universal adjustable sample holder allows for specimens with a width up to 200 mm and a maximum height of 530 mm, accommodating various material forms for both single and batch testing.

Q: When should I use the automatic calibration function instead of manual calibration?

A: Automatic calibration is recommended for routine testing and when consistent calibration is critical, while manual calibration allows for custom adjustments in specialized research or non-standard conditions.

Q: Where is the data from each test stored and how can it be exported?

A: Test data is stored internally and can be exported via USB or RS-232C interfaces, allowing easy integration with laboratory information systems and secure backup of results.

Q: What benefits does the VIDAS 2.0 software offer for hardness testing?

A: VIDAS 2.0 provides digital image analysis, comprehensive statistical data processing, and customizable reporting features, promoting efficient workflow and accurate data interpretation.

Q: How is the hardness value measured and displayed on the HT-1000AD?

A: Hardness values are calculated using the diamond Vickers indenter and displayed instantly (within 1 second) on the touchscreen digital display, with a resolution of 0.1 HV for detailed analysis.

Q: Can the tester be used in environments with variable temperature and humidity?

A: Yes, the HT-1000AD operates reliably within a temperature range of 10C to 35C and relative humidity 85%, making it suitable for most laboratory settings in India and beyond.
