Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000T with Vidas 2.0)

Name: Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000T with Vidas 2.0)
Brand: OM ENGINEERING INSTRUMENTS
Price: 1 INR
Availability: InStock

Price 1 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000T with Vidas 2.0) Specification

Automation Grade
Semi-automatic / Full-automatic

Response Time
<2 seconds

Operating Voltage
AC220V ±5%

Accuracy
±1% on certified reference blocks

Temperature
10~40°C

Power Supply
AC220V±5% 50-60Hz

Humidity
≤90%

Display Type
8-inch Capacitive Touch Screen Display

Mounting Type
Bench-top

Test Range
1gf~1000gf

Hardness
Micro Vickers (HV)

Frequency
50-60 Hz

Interface Type
USB, HDMI, LAN

Max Height
100 mm

Equipment Type
Micro Vickers Hardness Tester

Resolution
0.01 HV

Features
Automatic image analysis, integrated camera, auto hardness calculation, data storage and reporting, motorized turret, live digital imaging, VIDAS 2.0 software

Application
Measurement of micro hardness on metals, alloys, coatings, ceramics

Measuring Range
HV 1~HV 1000

Number of Specimens
1 specimen per cycle

Specimen Size
10 mm to 100 mm

Port Size
USB, HDMI

Dimension (L*W*H)
530X200X530 Millimeter (mm)

Usage
Laboratory, Quality Control, R&D, Educational use

Capacity
Single sample loading

Machine Weight
35 Kilograms (kg)

Test Speed
Manual / Automatic

Test Width
Standard sample stage, width up to 100 mm

Test Stroke
Upto 25 mm

Control Mode
Touch Screen Interface (VIDAS 2.0 Software Control)

Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000T with Vidas 2.0) Trade Information

Minimum Order Quantity
1 Number

Supply Ability
1 Number Per Day

Delivery Time
1 Week

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000T with Vidas 2.0)

Features

MANUAL EYEPIECE :Equipped with 10x Manual Eyepiece to measure the length of diagonal. The hardness value can be displayed directly on the LCD screen by entering the indentation diagonal length.

CAMERA PORT :Machine equipped with dual optical channel. 5 MP USB Camera is connected to one of the dual optical channels, other optical channel is for 10X eyepiece. Both optical channel works simultaneously.

ILLUMINATION SYSTEM :Halogen illumination unit with adjustable intensity. gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.

TEST FORCE :Wide range of test force (10gm to 1000gm) can be selected with external force selection knob. The test force is automatically displayed on the 7 inch LCD touch display.

DATA OUTPUT :Equipped with built-in thermal printer to take the print out the hardness result.

TURRET MECHANISM :Equipped with manual turret mechanism. The position of the indentor and objective lens can be switched manually.

Z-AXIS LIFTING SYSTEM :Side-Ways lifting system makes the z-axis movement more stable and accurate.

LCD TOUCH SCREEN PANEL :7 Inch LCD touch screen can visually display the hardness value, hardness conversion (4 conversion scales can be displayed at the same time), test force, dwell time, statistical data, upper & lower limit and brightness of optical system.

EMERGENCY SWITCH :Equipped with emergency stop switch.

Comprehensive Software Integration

The HT-1000T is equipped with VIDAS 2.0, an intuitive software suite that streamlines hardness measurement, automatic image analysis, and data management. The system allows easy storage, reporting, and exporting of results in multiple formats, ensuring efficiency in laboratory, R&D, and quality control settings.

Precision and Versatility in Hardness Testing

This tester features a diamond pyramid indenter and offers a wide measurement range (HV 1HV 1000). With adjustable loading times, motorized multi-position turret, and high-magnification objectives (10x, 40x), it is engineered for accurate, repeatable micro hardness evaluations on varied sample sizes and materials.

User-Friendly Touch Screen Control

An 8-inch capacitive touch screen interface ensures swift operation and easy navigation through test setup, execution, and reporting. The integrated high-resolution camera delivers live digital imaging, while the touch interface facilitates rapid configuration and on-the-spot results, ideal for busy laboratory environments.

FAQs of Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000T with Vidas 2.0):

Q: How does the HT-1000T Micro Vickers Hardness Tester operate?

A: The HT-1000T uses a diamond pyramid indenter with adjustable loads (1gf1000gf) to apply precise force on a specimen. Its motorized turret automatically positions objectives and the indenter under software control (VIDAS 2.0), while the integrated camera captures indentation images for automatic hardness calculation and analysis.

Q: What types of samples can I test with this instrument?

A: This tester is suitable for metals, alloys, coatings, and ceramics with specimen sizes ranging from 10 mm to 100 mm. The standard stage accommodates samples up to 100 mm wide and a maximum height of 100 mm, making it suitable for various research and industry applications.

Q: When should I use automatic versus manual test speed modes?

A: Automatic mode is recommended for high-throughput testing and consistent results; it is controlled via the touch screen and VIDAS 2.0 software. Manual mode gives the operator more direct control, which can be beneficial for delicate samples or custom testing needs.

Q: Where can data from the hardness tests be exported and in which formats?

A: Test data can be exported via USB or PC connectivity. VIDAS 2.0 enables exporting reports and results in CSV and PDF formats, facilitating documentation and data sharing across laboratory or industrial networks.

Q: What is the process for calibrating the HT-1000T?

A: Calibration is performed using certified reference blocks to ensure measurement accuracy (1%). The test process, load selection, and indentation are managed via the software. The systems intuitive interface guides users through calibration and verification steps.

Q: How does using the touch screen interface benefit daily testing routines?

A: The 8-inch capacitive touch screen streamlines operations by allowing fast test setup, immediate result viewing, and rapid reporting. It simplifies navigation between measurement modes and database management, improving workflow efficiency.

Q: What practical benefits does the VIDAS 2.0 software offer?

A: VIDAS 2.0 provides automatic indentation measurement, batch analysis, comprehensive database management, and report generation. Its automation reduces human error, accelerates data processing, and supports traceable, well-documented hardness testing for quality assurance and research.
