Portable Hardness Tester-II

Name: Portable Hardness Tester-II
Brand: OM ENGINEERING INSTRUMENTS
Price: 1 INR
Availability: InStock

Price 1 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Portable Hardness Tester-II Specification

Temperature
0°C~40°C

Dimension (L*W*H)
210x85x45 Millimeter (mm)

Mounting Type
Handheld

Hardness
Leeb Hardness (HL)

Test Range
170-960 HL

Equipment Type
Portable Hardness Tester

Operating Voltage
9V DC

Resolution
1 HL

Measuring Range
170-960 HL

Frequency
--

Accuracy
±4 HL(0.5% @ HL=800)

Interface Type
USB

Port Size
--

Specimen Size
Minimum thickness 3 mm

Features
Portable, Lightweight, Auto Power Off, Data storage

Application
Metal hardness testing

Automation Grade
Semi-automatic

Response Time
Instant

Power Supply
9V/500mA

Humidity
≤90% RH

Max Height
--

Gas Pressure
--

Number of Specimens
1

Display Type
LCD digital display

Usage
Field and laboratory use

Capacity
--

Machine Weight
0.6 Kilograms (kg)

Test Speed
--

Test Width
--

Test Stroke
--

Control Mode
Manual/Automatic

Portable Hardness Tester-II Trade Information

Minimum Order Quantity
1 Number

Supply Ability
1 Number Per Day

Delivery Time
1 Week

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Portable Hardness Tester-II

Application

Die cavity of molds.

Bearings and other parts.

Failure analysis of pressure vessel, steam generator and other equipment.

Heavy work piece.

The installed machinery and permanently assembled parts.

Material identification in the warehouse of metallic materials.

Rapid testing in large range and multi-measuring areas for large-scale work piece.

Specifications

Measuring range: HLD (170-960), HRC (17.9-69.5, HB (19-683), HV (80-1042), HS (30.6-102.6), HRA (59.1-88), HRB (13.5-101.7).

Measuring direction: 360

Battery pack : 6VNI-MH

Battery charger : 9V/500mA

Communication interface : USB2.0

Dimensions : 210x85x45mm (host)

Weight : about 0.6kg (host)

Portable Hardness Tester A

Large screen (128x64), showing all functions and parameters.

Test at any angle, even upside down.

Wide measuring range. it can measure the hardness of all metallic materials. Direct display of hardness scales HRB, HRC, HRA, HV, HB, HS, HL and strength values immediately.

Seven impact devices are available for special application. Automatically identify the type of impact devices

Large capacity memory could store 600 groups information including single measured value, mean value, impact direction, impact times, material and hardness scale etc.

Battery information indicates the rest capacity of the battery and the charge status.

User Calibration function.

USB port with the PC humanity multi-functions data proceeding software.

Original imported high speed thermal printer support the immediate printing function. It can save data permanently.

NI-MH rechargeable battery as the power source. Charge circuit integrated inside the instrument. Continuous working period of no less than 200 hours (EL off and no printing).

Auto power off to save energy.

Versatile Hardness Measurement

This device accommodates a wide range of hardness tests, including Leeb (HL), Brinell (HB), Rockwell (HRB, HRC), Vickers (HV), and Shore (HS). Whether in the lab or onsite, you can evaluate various metal materials with exceptional efficiency and consistent results.

User-Friendly and Portable Design

The Portable Hardness Tester-II features an ergonomic, handheld structure weighing only 0.6 kg, making it easy to carry and operate. The backlight LCD ensures clear readings even in varied lighting conditions, and a rugged carrying case adds protection for field use.

Reliable Data Management

With storage for up to 500 test groups, the built-in USB interface allows for prompt data transfer and reporting. The device also offers user calibration for tailored accuracy and supports both English and Chinese for broader accessibility.

FAQs of Portable Hardness Tester-II:

Q: How do I use the Portable Hardness Tester-II to measure metal hardness?

A: Simply power on the device, select your desired hardness scale, and position the impact device against the metal specimen. Initiate the test in either manual or automatic control mode, and view instant results on the digital LCD display.

Q: What types of metals can be tested with this hardness tester?

A: The Portable Hardness Tester-II is designed for metal hardness testing and can measure a variety of alloys and metal types, provided the minimum specimen thickness is 3 mm.

Q: When is user calibration necessary, and how is it performed?

A: User calibration is recommended before critical or repeated testing for optimal accuracy. To calibrate, follow the instructions in the user manual by comparing readings against a standard reference block and adjusting settings as needed.

Q: Where can I use this tester? Is it suitable for fieldwork?

A: Yes, the tester is ideal for both laboratory and field use due to its portable, lightweight design and robust carrying case, making it convenient to transport and set up anywhere metal hardness testing is required.

Q: What is the data storage and retrieval process for test results?

A: The tester can store up to 500 groups of measurement data, which you can retrieve and download via the USB interface to your computer for record keeping and analysis.

Q: What benefits does the backlight LCD display provide?

A: The backlight LCD display ensures measurement readings are visible in various lighting conditions, enhancing usability in both brightly lit labs and dim field environments.
