Touch Screen Vickers Hardness Tester (VHT-AT Series with Vidas 2.0)

Name: Touch Screen Vickers Hardness Tester (VHT-AT Series with Vidas 2.0)
Brand: OM ENGINEERING INSTRUMENTS
Price: 1 INR
Availability: InStock

Price 1 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Touch Screen Vickers Hardness Tester (VHT-AT Series with Vidas 2.0) Specification

Application
Metals, Alloys, Micro Hardness Testing

Specimen Size
Max: 200mm

Measuring Range
1HV–3000HV

Frequency
50-60Hz

Max Height
200 mm

Features
Automated Measurement, Image Analysis, Data Storage, Real-time Curve

Power Supply
AC220V±5% 50-60Hz

Test Range
1HV–3000HV

Dimension (L*W*H)
585X200X630 Millimeter (mm)

Port Size
Standard

Response Time
<2s

Mounting Type
Benchtop

Humidity
≤85%

Hardness
Vickers (HV)

Automation Grade
Automatic

Resolution
0.1 HV

Temperature
10°C–30°C

Number of Specimens
Multiple

Display Type
7 Touch Screen LCD

Interface Type
USB, RS232

Operating Voltage
AC220V

Accuracy
±1.5%

Usage
Lab, Industry Quality Control

Capacity
Standard

Machine Weight
42 Kilograms (kg)

Test Speed
Standard

Test Width
200 mm

Test Stroke
Auto, Motorized

Control Mode
Touch Screen / Automatic

Touch Screen Vickers Hardness Tester (VHT-AT Series with Vidas 2.0) Trade Information

Minimum Order Quantity
1 Number

Payment Terms
Cheque, Telegraphic Transfer (T/T)

Supply Ability
1 Number Per Day

Delivery Time
1 Week

Main Domestic Market
All India

About Touch Screen Vickers Hardness Tester (VHT-AT Series with Vidas 2.0)

Features

MANUAL EYEPIECE :Equipped with 10x Manual Eyepiece to measure the length of diagonal. The hardness value can be displayed directly on LCD screen by entering the indentation diagonal length.

CAMERA PORT :Machine equipped with dual optical channel, one optical channel for 10X eyepiece and another optical channel is for camera by which machine can be upgraded into computerized / computer controlled model. Both optical channel works simultaneously.

ILLUMINATION SYSTEM :Halogen illumination unit with adjustable intensity gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.

AUTO TURRET MECHANISM :Equipped with auto turret mechanism. Auto turret perform a series of operation and measuring lens automatically comes back to central position after making indentation. The position of the indenter and the objective lens can be automatically switched using touch panel.

DATA OUTPUT :Equipped with built is thermal printer to take the print out the hardness result USB port is also available to get the data in pendrive.

TEST FORCE :Wide range of test force can be selected with external force selection knob. The test force is automatically displayed on the 7 inch LCD touch display.

LCD TOUCH SCREEN PANEL :7 Inch LCD touch screen can visually display the hardness value, conversion hardness, test force, dwell time, statistical data, upper & lower limit and brightness of optical system.

EMERGENCY SWITCH :Equipped with emergency stop switch.

Advanced Touch Screen Controls

The VHT-AT Series features a 7-inch LCD touch screen, making test setup, operation, and data visualization exceptionally easy. Its intuitive interface simplifies the workflow, allowing users to quickly adjust parameters, initiate tests, and review results, thereby increasing productivity and user confidence in both laboratory and industrial settings.

Powerful Automation and Accuracy

Engineered for precision, the VHT-AT offers motorized, automatic stage movement and a force selection range from 10g to 1000g. With a built-in calibration block, resolution of 0.1 HV, and 1.5% accuracy, users can ensure trustworthy results across micro hardness applications. Automatic positioning and measurement further reduce operator error.

Comprehensive Data and Connectivity

Equipped with modern connectivity, the tester enables easy data export via USB, print, Excel, and RS232 interfaces, ensuring seamless transfer to your quality control systems. Real-time curve display, onboard storage, and integrated image analysis via Vidas 2.0 software facilitate detailed reporting and recordkeeping for compliance and process optimization.

Versatile Application for Multiple Specimens

With a test width and specimen height capacity up to 200 mm, the VHT-AT Series accommodates a diversity of metals, alloys, and other materials. Automated measurement, high-brightness LED lighting, and digital imaging capabilities make it ideal for laboratories, factories, and quality control departments needing reliable micro hardness testing results.

FAQs of Touch Screen Vickers Hardness Tester (VHT-AT Series with Vidas 2.0):

Q: How does the Touch Screen Vickers Hardness Tester (VHT-AT Series) ensure accurate and consistent test results?

A: The VHT-AT Series uses a built-in standard calibration block for regular checks, automated force application from 10g to 1000g, and advanced Vidas 2.0 micro hardness analysis software. Its auto stage with X-Y precision and motorized movement, in combination with a digital integrated camera, reduces manual errors and ensures repeatable, high-accuracy results.

Q: What materials and specimen sizes can be tested using the VHT-AT Series with Vidas 2.0?

A: This tester accommodates a variety of metals and alloys for micro hardness testing. It supports specimens up to 200 mm in width and height, making it suitable for both small samples and larger components within laboratory or industrial settings.

Q: When and where can the VHT-AT Series be used most effectively?

A: The VHT-AT Series is ideal for routine testing in quality control, research laboratories, and manufacturing environments. It operates reliably within a temperature range of 10C30C and relative humidity up to 85%, making it suitable for controlled indoor environments.

Q: Where does the data from hardness tests get stored or exported?

A: Data can be directly exported and stored via USB, printed, saved as Excel files, or transmitted using the RS232 interface. This versatility allows easy integration with laboratory information management systems or archival for compliance and reporting.

Q: What is the process for conducting a hardness test with the VHT-AT Series?

A: Users position the specimen on the auto stage, select the appropriate test force and dwell time using the touch screen, and initiate the test. The device automatically applies the load, captures images, analyzes indentations, and provides instant results, which can then be saved or exported as needed.

Q: How does the automated stage benefit the testing workflow?

A: The auto stage with X-Y precision ensures accurate specimen positioning and repeatable measurement locations. This feature speeds up testing, minimizes human error, and allows testing of multiple specimens efficiently, thus enhancing overall throughput and data reliability.

Q: What are the main advantages of using the VHT-AT Series with Vidas 2.0 for micro hardness testing?

A: Key benefits include automated measurement, touch screen ease of use, high-accuracy results, flexible data management, integrated image analysis, rapid response times, and broad compatibility with many materials and specimen sizes. These features streamline testing and bolster quality assurance processes.
