Fully Automatic Touch Screen Micro Vickers Hardness Tester (HT-1000ADT-XYZ with Vidas 6.0) Specification

Hardness
Micro Vickers (HV)

Response Time
Instantaneous on input

Mounting Type
Benchtop

Equipment Type
Fully Automatic Touch Screen Micro Vickers Hardness Tester

Specimen Size
Up to 100 mm x 100 mm

Interface Type
USB, RS232, Ethernet

Display Type
7-inch Touch Screen LCD

Number of Specimens
Up to 99 programmable sequences

Frequency
50-60 Hz

Application
Microhardness measurement of metals, ceramics, coatings

Accuracy
≤1% (HV0.2 ~ HV1)

Test Range
1~4500 HV

Port Size
Standard USB, RS232

Measuring Range
1 HV ~ 2950 HV

Automation Grade
Fully Automatic

Dimension (L*W*H)
530X200X530 Millimeter (mm)

Operating Voltage
AC220V ±5% 50-60Hz

Features
Automatic turret, autofocus, motorized XY and Z; image analysis software (Vidas 6.0); programmable routines; statistics

Temperature
10-35°C

Resolution
0.01 μm

Max Height
Specimen max height 40 mm

Humidity
≤90% RH

Power Supply
AC220V±5% 50-60Hz

Usage
Microhardness testing in labs, research, QA

Capacity
Single and Batch Testing

Machine Weight
35 Kilograms (kg)

Test Speed
Fully Automatic

Test Width
XYZ-motorized stage; up to 100 mm

Test Stroke
Auto X 100 mm, Y 100 mm, Z 40 mm

Control Mode
Touch Screen Control

Fully Automatic Touch Screen Micro Vickers Hardness Tester (HT-1000ADT-XYZ with Vidas 6.0) Trade Information

Minimum Order Quantity
1 Number

Payment Terms
Cheque, Telegraphic Transfer (T/T)

Supply Ability
1 Number Per Day

Delivery Time
1 Week

Main Domestic Market
All India

About Fully Automatic Touch Screen Micro Vickers Hardness Tester (HT-1000ADT-XYZ with Vidas 6.0)

Features

DIGITAL EYEPIECE :Equipped with 10x Digital Eyepiece to directly measure the length of the diagonal. The hardness value can be displayed directly and there is no need to enter the length of the diagonal.

HIGH RESOLUTION CAMERA :Machine equipped with dual optical channel. 5 MP USB Camera is connected to one of the dual optical channels, other optical channel is for 10X eyepiece. Both optical channel works simultaneously.

ILLUMINATION SYSTEM :Halogen illumination unit with adjustable intensity. gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.

TEST FORCE :Wide range of test force (10gm to 1000gm) can be selected with external force selection knob. The test force is automatically displayed on the 7 inch LCD touch display as well as in PC.

AUTO TURRET MECHANISM :Auto turret perform a series of operation automatically. Measuring lens automatically comes back to central position after making indentation. The position of the indenter and the objective lens can be automatically switched from PC as well as using touch panel.

MOTORIZED Z-AXIS LIFTING SYSTEM :Motorized Side-Ways lifting system makes the z-axis movement automaticaly more stable and accurate.

LCD TOUCH SCREEN PANEL :7 Inch LCD touch screen can visually display the hardness value, conversion hardness (4 conversion scales can be displayed at the same time), test force, dwell time, statistical data, upper & lower limit and brightness of optical system.

MOTORIZED XY TABLE :Equipped with motorized XY table.

DATA OUTPUT :Equipped with built in RS-232 port.

EMERGENCY SWITCH :Equipped with emergency stop switch.

Precision and Automation for Microhardness Testing

This fully automatic tester offers state-of-the-art automation in micro Vickers hardness measurement. Its programmable motorized XYZ stage allows for precise placement and testing of multiple specimens. With an advanced autofocusing imaging system and automatic indentation recognition, users can achieve consistently accurate and reproducible results, making it ideal for laboratories, research centers, and quality assurance settings.

User-Friendly Interface and Versatile Software

The intuitive 7-inch touch screen, paired with Vidas 6.0 analysis software, provides a seamless user experience. Features include multi-point testing, mapping, statistical analysis, and comprehensive report generation in multiple languages. Connectivity options such as USB, RS232, and Ethernet, along with compatibility with Windows 7/10, ensure easy integration into existing lab networks.

Robust Construction and Flexible Applications

Constructed for stability and long-term use, the benchtop tester accommodates specimens up to 100 x 100 mm and 40 mm height. It is suitable for microhardness testing of metals, ceramics, and coatings, supporting both single and batch testing with accurate and reliable results. Automatic functions and precise load control make it highly efficient for routine QA or complex research tasks.

FAQs of Fully Automatic Touch Screen Micro Vickers Hardness Tester (HT-1000ADT-XYZ with Vidas 6.0):

Q: How does the fully automatic Micro Vickers Hardness Tester work?

A: The system utilizes a Vickers diamond pyramid indenter, an auto-focusing digital camera, and a motorized XYZ stage to automatically position, indent, and measure specimens. Its software recognizes indentations, calculates hardness, performs statistical analysis, and generates reports without manual intervention.

Q: What types of materials can I test with this equipment?

A: This hardness tester is suitable for microhardness measurements on metals, ceramics, and coatings, making it ideal for use in labs, research, and quality assurance across a wide range of industries.

Q: When should I choose this fully automatic model over a manual tester?

A: Select this model if your lab requires high throughput, complex mapping, or batch testing, or if you prioritize consistency and objectivity in measurements. Automation significantly reduces operator bias and boosts productivity.

Q: Where can the test data be exported or saved?

A: Test results and statistical data can be exported directly to Excel and PDF files, printed over a network, or transferred via USB, RS232, or Ethernet. This flexibility allows seamless integration into lab management systems.

Q: What is the process for measuring hardness with this tester?

A: To test, load your specimen onto the stage, select or program the required test routine on the touch screen, and start the sequence. The machine automatically performs indentations, focuses, acquires images, evaluates hardness, and compiles reports.

Q: How does the equipment benefit laboratory testing and quality assurance?

A: The fully automatic operation ensures rapid, repeatable, and objective hardness measurements. Features like multi-point mapping, batch testing, and instant reporting simplify workflow, increase lab efficiency, and enhance data reliability.
