Load Cell Based Vickers Hardness Tester

Get a Price/Quote

MOQ : 1 Number

Load Cell Based Vickers Hardness Tester Specification

Dimension (L*W*H)
585X200X630 Millimeter (mm)

Power Supply
AC220V±5% 50-60Hz

Voltage
AC220 Watt (w)

Power
AC220 Volt (v)

Machine Weight
42 Kilograms (kg)

Load Cell Based Vickers Hardness Tester Trade Information

Minimum Order Quantity
1 Number

Supply Ability
1 Number Per Day

Delivery Time
1 Week

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Load Cell Based Vickers Hardness Tester

Features

MANUAL EYEPIECE :Equipped with 10x Manual Eyepiece to measure the length of diagonal. The hardness value can be displayed directly on LCD screen by entering the indentation diagonal length.

ILLUMINATION SYSTEM :Halogen illumination unit gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.

LCD SCREEN :80X25mm LCD Screen can visually display the hardness value, conversion hardness, test force and dwell time.

CAMERA PORT :Machine equipped with dual optical channel, one optical channel for 10X eyepiece and another optical channel is for camera by which machine can be upgraded into computerized / computer controlled model. Both optical channel works simultaneously.

TEST FORCE :All the test force is applied by load cell. The high quality load sensing system can do a wide-range of vickers test by one load cell.

AUTO TURRET MECHANISM :Equipped with auto turret mechanism. Auto turret perform a series of operation and measuring lens automatically comes back to central position after making indentation. The position of the indenter and the objective lens can be automatically switched using keypad.

EMERGENCY SWITCH :Equipped with emergency stop switch.

Advanced Load Cell Technology

The Vickers Hardness Tester employs load cell technology, ensuring precise force application during testing. This innovative approach increases measurement accuracy by minimizing errors associated with manual weights or older mechanisms, making it highly reliable for critical material analysis.

Optimized for Varied Environments

With compact dimensions and a moderate weight of 42 kg, this tester is suitable for both laboratory and industrial settings. It operates efficiently on a standard AC220V power supply, accommodating most Icelandic facilities without the need for specialized electrical setups.

FAQs of Load Cell Based Vickers Hardness Tester:

Q: How does a load cell enhance the performance of a Vickers Hardness Tester?

A: A load cell ensures precise and consistent force application during hardness testing, resulting in higher accuracy and repeatability compared to traditional weight-based systems. This innovation leads to dependable results for various material samples.

Q: What materials can be tested with this Vickers Hardness Tester?

A: This instrument is suitable for a wide range of metals and alloys. It is ideal for applications in metallurgy, manufacturing, and research where precise hardness measurement is essential.

Q: When is calibration required for optimal accuracy in hardness testing?

A: It is recommended to calibrate the tester periodically, typically before critical testing sessions or after moving the device. Regular calibration ensures the load cell continues to provide accurate readings.

Q: Where can I purchase or source this tester in Iceland?

A: You can acquire this Load Cell Based Vickers Hardness Tester from authorized dealers, exporters, manufacturers, retailers, suppliers, or wholesalers operating within Iceland.

Q: What is the process for conducting a hardness test using this machine?

A: Place the sample on the stage, select the appropriate load, and initiate the test. The load cell applies force to the indenter, which creates an impression on the material. The tester then measures the impression and calculates the Vickers hardness value.

Q: How is the tester powered and what are its electrical requirements?

A: The tester runs on an AC220V5% power supply at 50-60Hz, making it compatible with standard electrical systems commonly used in Iceland.

Q: What are the primary benefits of using a Load Cell Based Vickers Hardness Tester?

A: This tester offers enhanced accuracy, reduced operator influence, and reliable results, making it a valuable asset for laboratories and industries focused on maintaining material quality standards.
